RS PRO 3.3μF Aluminium Electrolytic Capacitor 63V dc, Radial, Through Hole, Конденсатор

1815515
Производитель: RS PRO
Цена за шт. (норма упаковки 100 шт)
21.00 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

RS PRO Electrolytic Capacitor

The RS PRO 3.3μF through-hole mount electrolytic capacitor has a voltage rating of 63VDC and leakage current of 2μA. This low impedance capacitor has dimensions of 5mm x 11mm (diameter x length). This capacitor is designed with a safety vent construction.

Features and Benefits

• Tolerance: ±20%
• Lifetime: 1000 hours
• Ripple current: 50mA
• Dissipation factor: 9%
• Lead pitch: 2mm
• Load life: 3000∼10000 hours at 150 °C
• Impedance: 2.06ohm
• Operating temperature ranging between -40°C and 105°C

Applications

• Used in communication equipment
• Switching power supply
• Industrial measuring instruments

Certifications

• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007

Техническая спецификация
pdfRS PRO Datasheet
