4052899490734, Osram LED Driver, 42V Output, 29.4W Output, 500mA Output, Драйвер светодиодов

Osram LED Driver

The Osram OT FIT 40/220-240/1A0 LT2 LP is a non-dimmable LED driver with a compact constant current. It provides a wide range of application due to the output power range of up to 40W.

Features and Benefits

• Cable clamp kit for independent mounting
• Cable clamp kit for independent mounting
• Fulfil safety requirement due to overload, over temperature protection
• Fulfil safety requirement due to overload, over temperature protection
• High efficiency
• High efficiency
• High flexibility due to four different output currents
• High flexibility due to four different output currents
• Input voltage supply 198VAC to 264VAC and 176VDC to 276VDC
• Lifetime up to 50,000h (temperature at T c = 70°C, max. 10% failure rate)
• Lifetime up to 50,000h (temperature at T c = 70°C, max. 10% failure rate)
• Line frequency is 0Hz/50Hz/60Hz
• Line frequency is 0Hz/50Hz/60Hz
• Line voltage is between198V to 264V
• Line voltage is between198V to 264V
• Nominal supply voltage is between 220V to 240V
• Nominal supply voltage is between 220V to 240V
• Temperature range at storage is between -40°C and 85°C
• Temperature range at storage is between -40°C and 85°C

Applications

• Independent mounting via cable clamp kit possible
• Luminaires with flexible current setting
• Suitable for downlights, spotlights and LED panels
• Suitable for indoor SELV installations
• Suitable for luminaires of protection classes I and II

Certifications

• CE certified
• EN 55015
• IEC 61000-3-2
• IEC 61347-1
• IEC 61347-2-13
• IEC 61547
• IEC 62384
• IP20 rating

Datasheet
