EMMS-ST-57-M-S-G2, Festo EMMS-ST Series Hybrid Stepper Motor, 48 V, 1.8°, 6.35mm Shaft, Шаговый двигатель

Festo Stepper Motor, 5A Nominal Motor Current, 1.1kg Weight - EMMS-ST-57-M-S-G2

Achieve on-the-dot rotation on your industrial equipment with this stepper motor from Festo. It divides a turning cycle into a series of repeatable 1.8° pulses, so it's just the thing for applications that need precise positioning. You'll find it fits the bill when it comes to fast-paced devices, as its maximum speed is 1940rpm. The hybrid design means that the power of two motors is packed into one unit, giving you a high level of performance. Thanks to a current rating of 5A, this is a practical choice for low-current-consuming tasks.

Features & Benefits

• IP54 rating indicates it's resistant to dust and water splashes
• Low power consumption of 10W for energy efficiency
• 9-pin D-sub plug for easy communication with serial devices
• Wide operating temperature range of -10°C to +50°C for use in challenging settings

Applications

• Variable frequency drives
• CNC equipment
• 3D printers

What's meant by the insulation protection class of this stepper motor?

The insulation protection class of the motor shows how much heat the insulators in its windings can resist. This unit falls into class B, so its threshold is +130°C. Using it above this limit could reduce your motor's service life.

Datasheet EMMS-ST-57-M-S-G2
