EMMS-ST-87-L-SE-G2, Festo EMMS-ST Series Hybrid Stepper Motor, 9.3Nm Torque, 48 V, 1.8°, 11mm Shaft, Шаговый двигатель

Festo Stepper Motor, Class-B Insulation, IP54 Rating - EMMS-ST-87-L-SE-G2

Precisely driven movements are a piece of cake when you use this stepper motor from Festo. Its advanced hybrid technology boosts accuracy for your most demanding applications by letting you make tiny half-stepping and micro-stepping motions. The unit's support for rotational speeds up to 430rpm means it's capable of safely driving high-velocity tasks with precision. As it moves without generating much friction, you can trust it won't produce excess heat that could damage your motor's sensitive internal windings. Class-B insulation also helps with this, as it stops heat from seeping through the device.

Features & Benefits

• High axial and radial load tolerances of 65N and 200N make it a great shout for driving heavy industrial equipment
• Works reliably across a broad ambient temperature range from -10°C to +50°C
• Stepper angle tolerance of ±5% means it can safely handle minor misalignments
• Motor and braking torques of 9.3Nm and 2Nm for prompt starting and stopping

Applications

• Robotics systems
• Process automation
• Camera platforms

Does this stepper motor come have an IP rating?

Yes. This unit's IP54 rating means it has protection against dust and splashes of water from all directions.

Datasheet EMMS-ST-87-L-SE-G2

Instruction Sheet - EMMS-ST Stepper Motor

Brochure - Simply Part of the Solution

Catalogue - Automation Technology
