Mean Well DIN Rail Power Supply
The Mean Well HDR series DIN rail 3-phase power supply has a universal input voltage ranging between 340VAC and 550VAC/480VAC and 780VDC with a built-in passive PFC function. It has an ultra-slim body of 63mm width, which allows space-saving inside the cabinets. It is made from metal housing that enhances the unit's power dissipation. It is equipped with constant current mode for overload protection, fitting various inductive or capacitive applications. The rated output current is 10A at 24VDC output voltage. Adjustable output voltage ranging between 24VDC and 28VDC.
Features and Benefits
Built-in constant current limiting circuit
Cooling by free air convection
DC output voltage adjustable
High efficiency up to 92%
LED indicator for power ON
No load power consumption is less than 0.3W
Operation temperature ranging between -30°C and 70°C
Power rating is up to 240W
Ripple factor and noise is 100mV
Short circuit and overvoltage protection
Applications
Electro-mechanical apparatus
Factory automation
Industrial control system
Semiconductor fabrication equipment
Certifications
CE Certified
EN6100
UL approved
Datasheet TDR-240-24Installation Manual| Самовывоз со склада поставщика в Екатеринбурге | Забираете сами или вызываете курьера |
