6EP3333-7SB00-0AX0, Siemens SITOP PSU6200 Switch Mode DIN Rail Power Supply, 85 → 264V ac ac, dc Input, 24V dc dc Output, 5A Output,, Блок питания

Siemens Switch-Mode DIN Rail Power Supply, 120W Power Rating, 5A Output Current - SITOP PSU6200 Series - 6EP3333-7SB00-0AX0

Distribute electrical energy to DIN rail connected network devices with this power supply unit (PSU) from Siemens. The device is designed to regulate and send power to single-phase electrical components on your network. Its wide input voltage range of 85 to 264V AC means it can handle substantial power fluctuations without being damaged. It also has an Extra-Power feature that supplies up to 150% of the rated current for short periods to keep your devices running when the current supply is faulty. This PSU makes good use of the energy it receives and has an efficiency of 90.2%. Its compact dimensions of 35 (width) x 125 (depth) x 135mm (height) make it a space-efficient solution for small enclosures.

• Output current of 5A for energy efficiency
• Green LED status indicator allows for troubleshooting at a glance
• Wide operating temperature range of -25°C to +70°C for use in demanding environments

How does this PSU react to short-circuits?

During a short-circuit fault, this PSU shuts down and makes periodic restart attempts in order to protect the devices connected to it.

Datasheet 6EP3333-7SB00-0AX0

Brochure

Catalogue - SITOP Power Supply

Manual - SITOP Power Supply
