800T-QAH2G, Allen Bradley 800T Series Green Illuminated Momentary Push Button Head, 30mm Cutout, IP67, IP69K

Allen Bradley Push Button Head, Green Illuminated, 12 to 130V AC/DC Voltage Rating - 800T-QAH2G

Use this push button head from Rockwell Automation's Allen Bradley range to activate your push button mechanism. It's designed to let you quickly halt a machine, preventing accidents from happening. Thanks to its green colouring, you can easily colour-code it for quick identification in a busy panel. The rugged metal body offers resistance to impact and vibration, so this unit can withstand demanding operations. As it comes with IP67 and IP69K ratings, indicating full protection against dust, steam and water immersion up to 1m, you can rely on it to work safely in demanding environments.

• Wide operating temperature range between -40°C and +55°C to withstand harsh conditions
• Voltage rating between 12 and 130V AC/DC for versatile use
• Integrated LED illumination for quick identification in low-light settings
• Electrical design life cycles of 1,000,000 for lasting use

Standards and Certifications

• UL 508
• CCC
• CSA Certified
• CE Marked
• EN ISO 13850

30.5mm Type 4/13 Mom. Contact PB-Illum., Green, Ext. Hd w/ Guard, LED, 12-130V AC/DC, 1 NO-1 NC

What's meant by the momentary actuation?

The momentary actuation design means this push button head will functions while pressed and then automatically returns to its original position when released. This eliminates the need for a manual reset.

Datasheet 800T-QAH2G

Brochure - 800T/H 30 mm Push Buttons

Catalogue - Essential Components Selection Guide
