Eliminates External Components and Reduces Total Cost
No Schottky-Synchronous Operation for High Efficiency and Reduced Cost
Internal compensation for Stable Operation at Any Output Voltage
All Ceramic Capacitor Solution: Ultra-Compact Layout with as Few as Eight External Components
Reduce Number of DC-DC Regulators to Stock
Wide 4.5V to 60V Input Voltage Range
0.9V to 90% VIN Output Voltage
Delivers Up to 3.5A Over Temperature
100kHz to 2.2MHz Adjustable Frequency with External Synchronization
MAX17504S Allows Higher Frequency Of Operation
Available in a 20-Pin, 5mm x 5mm TQFN Package
Reduce Power Dissipation
Peak Efficiency > 90
PFM and DCM Modes for High Light-Load Efficiency
Shutdown Current = 2.8FA (typ)
Operate Reliably
Hiccup-Mode Current Limit and Autoretry Startup
Built-In Output Voltage Monitoring—(Open-Drain RESET Pin)
Resistor Programmable EN/UVLO Threshold
Adjustable Soft-Start and Pre-Biased Power-Up
High Industrial -40°C to +125°C Ambient OperatingTemperature Range/-40°C to +150°C Junction Temperature Range
Applications
