1565917-4, TE Connectivity 0.6mm Pitch 200 Way, Right Angle SMT Mount DDR1, DDR2 DIMM Socket ,1.8 V ,500.0mA, Разъем

TE Connectivity 1565917-4

DRAM Type=Double Data Rate (DDR), Connector System=Cable-to-Board, Profile=Standard, Row-to-Row Spacing=6.2 mm, Sealable=No, Center Key=None, Module Orientation=Right Angle, Number of Positions=200, Number of Rows=2, Keying=Standard, DRAM Voltage=1.8 V, SGRAM Voltage=1.8 V, Ejector Type=Locking, Contact Base Material=Copper Alloy, Contact Mating Area Plating Material=Gold Flash, Contact Current Rating (Max)=.5 A, Socket Type=Memory Card, Insertion Style=Cam-In, PCB Mount Retention Type=Solder Peg, PCB Mounting Style=Surface Mount, Connector Mounting Type=Board Mount, Centerline (Pitch)=.6 mm, Housing Color=Black, Stack Height=5.2 mm, Operating Temperature Range=-55 – 85 °C, Circuit Application=Power, UL Flammability Rating=UL 94V-0, Packaging Method=Tape & Reel, Packaging Quantity=150

Datasheet
