RS PRO Analogue Panel Ammeter 1 (Input)mA DC, 48mm x 48mm, 1 % Moving Coil, Амперметр

RS PRO DC Analogue Panel Ammeter

The RS PRO 48mm x 48mm cut-out DC analogue panel ammeter has a measurement range of 0mA to 1mA input. The DIN style panel meter comprises permanent magnet moving coil movements and indicates an average value. This movement consists of a magnet, aluminium coil suspended on pivots, hairspring, and jewel mechanism. The scales are linear and calibrated down to zero. High currents are measured with separate shunts attached on the rear side of the meter. The meter is housed in a moulded polycarbonate case.

Features and Benefits

• Operating temperature ranges between -10°C and 65°C
• Accuracy: 1%
• Pointer: Knife-edge type
• Pointer deflection: 0° to 90°
• DC Ammeter nominal range: 15uA to 100A
• Shock resistance: 15g for pulse duration of 11 milliseconds
• Moulded square case suitable for mounting control/switchgear panels in machinery consoles
• Overload: 1.2 times nominal current (continuous)
• Relative humidity: Less than 75% annual average (noncondensing)

Certifications

• UL 94 V-0 approved
• 2014/30/EC (EMC directive)
• 2014/35/EC (low voltage directive)
• CE certified
• IP52 rated
• EN 61010
• VDE 0100-410: 2018-10 approved
• IEC 529
• IEC 61010
• ISO 20653: 2006-08
