2CSS245102R0104, ABB SN201 MCB, 1P+N, 10A Curve C, 230V AC, 4.5 kA Breaking Capacity, Автоматический выключатель

ABB MCB, Type-C Tripping, 10A Current Rating - SN201 Series - 2CSS245102R0104

Need to shield your equipment against overloads and short circuits? Get behind this MCB from ABB. Its type-C tripping characteristics mean it trips when the current is 5 to 10 times its rated current of 10A. This makes it just the thing for protecting systems where high surge levels are likely, without the risk of nuisance tripping. A switch on the front makes it a breeze to operate. The contact position is clear as day, thanks to red and green indicators that let you know whether the device is on or off.

Features & Benefits

• Label carrier lets you mark the unit for ease of identification
• DIN rail mounting for installation in a snap
• Low power loss of 1.9W per pole for energy-efficient operation
• Compact dimensions of 69 (L) x 18 (W) x 85mm (H) to maximise packing space on your rail
• Light weight of 110g puts minimal strain on your setup

Applications

• Public buildings
• Offices
• Hospitals

What's the current rating of this MCB?

It has a current rating of 10A, so it's a good choice for use in low-power systems.

Datasheet 2CSS245102R0104
