1SMA5916BT3G, onsemi, 4.3V Zener Diode ±5% 1.5 W SMT 2-Pin CASE 403D, Стабилитрон

Zener Diodes 1.5W, 1SMA59xxBT, SZ1SMA59xxBT Series, ON Semiconductor

This 1.5 W Zener diode is designed for general purpose voltage regulation applications.

Standard Zener Breakdown Voltage Range – 3.3 V to 68 V
ESD Rating of Class 3 (>16 kV) per Human Body Model
Flat Handling Surface for Accurate Placement
Package Design for Top Side or Bottom Circuit Board Mounting
Low Profile Package
Available in Tape and Reel
Ideal Replacement for MELF Packages
Mechanical Characteristics:
Case: Void-free, transfer-molded plastic
Finish: All external surfaces are corrosion resistant with readily solderable leads
Maximum Case Temperature for Soldering Purposes: 260 °C for 10 seconds
POLARITY: Cathode indicated by molded polarity notch or cathode band.

Pb-Free Packages are Available
PPAP capable
SZ Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirement

Zener Diodes, ON Semiconductor

Datasheet 1SMA5916BT3G
