5SV1316-6KK06, Siemens RCBO, 6A Current Rating, 1P+N Poles, 30mA Trip Sensitivity, Type A, SENTRON Range, Автоматический выключатель

Siemens RCBO, Instantaneous Break Time, DIN Rail Mount - SENTRON Series - 5SV1316-6KK06

Save space in your distribution panel with this RCBO from Siemens. As it protects equipment against both residual current and overload, you'll only need one module instead of two. This means you can maximise your packing efficiency and install more protection devices into an existing system. The unit has an instantaneous break time, so it reacts immediately to current imbalances to safeguard people and machinery from power surges. Low power dissipation of 0.7W makes it energy efficient, as minimal power is wasted through heat. Choose this RCBO for harsh industrial applications, like automotive manufacturing and shipbuilding.

Features & Benefits

• Mechanical life of up to 10,000 switching cycles for reliability over an extended period
• IP20-rated enclosure (when correctly installed and wired) is touch-proof and protected against objects larger than 12mm
• Halogen-free, so emits no toxic fumes in the event of a fire
• Slides onto a DIN rail for quick and simple installation

How big is this RCBO?

This breaker has compact dimensions of 17.6 (L) x 70 (W) x 89.8mm (D).

How do I wire this device?

This RCBO has screw terminals, so all you need is a screwdriver to securely attach wires.
