STMicroelectronics STG719STR Multiplexer Switch IC, 1, 6-Pin SOT-23, Аналоговый умножитель

The STG719 is a high-speed SPDT (single pole double throw) switch fabricated in silicon gate C2MOS technology. It is designed to operate from 1.8 V to 5.5 V, making this device ideal for portable applications, audio signal routing, video switching, mobile, and communication systems. It offers 4 Ω ON-resistance max at 5 V, 25 °C and very low ON-resistance flatness. Additional key features include a fast switching speed (tON = 7 ns and tOFF = 4.5 ns), break before make delay time, and low power consumption. All inputs and outputs are equipped with protection circuits against static discharge, giving them ESD immunity and transient excess voltage. It is available in the commercial and extended temperature range.

High speed:
tPD = 0.3 ns (typ.) at VCC = 5 V
tPD = 0.4 ns (typ.) at VCC = 3.3 V
Low power dissipation:
ICC = 1 μA (max.) at TA = 25 °C
Low "ON" resistance:
RON = 4 Ω (max. TA = 25 °C) at VCC = 5 V
RON = 6 Ω (typ.) at VCC = 3 V
Wide operating voltage range:
VCC (opr) = 1.8 V to 5.5 V single supply
