1755833, Phoenix Contact 5.08mm Pitch 12 Way Pluggable Terminal Block, Header, Solder Termination

Phoenix Contact CLASSIC COMBICON MSTBVA 5.08mm PCB Headers

Phoenix Contacts MSTBVA PCV headers are known worldwide for there easy and intuitive design, but also connection technology. These PCB headers are vertical connection so you can have multi-row arrangement on your PCB and can be easily wave soldered onto your board meaning they make great PCB headers for large productions. Talking of large productions, these headers come in a variety of sizes and pins so you can have one header for all your designs, reducing cost and keeping things effortless with mating connectors.

MSTBVA PCB header are green in colour to go hand in hand with the other Phoenix Contact accessories, feature a 12 A nominal current and have a cross section of 2.5mm.

Features and benefits:

• Pitch: 5.08mm


• Worldwide known design makes mounting to other connectors easy


• Total flexibility in design – thanks to multiple pins with the same design you can have one header for all


• Closed contour for optimum stability of the plug-in connection


• Wave soldered to PCB board so you can incorporate it easily into any design

Approvals

UL; CSA

Phoenix Contact Straight PCB Header, 12 Way, 1 Row - MSTBVA 2,5/12-G-5,08 - 1755833

Use this PCB header from Phoenix Contact to establish multiple electrical links on a single connection block. Its 12-way setup provides an allowance for you to transmit several signals at the same time, reducing the need for excess cabling. You can install this header by soldering it directly onto your PCB, creating a reliable, permanent connection.
This component has a green polyamide body that offers resistance to impact and abrasion, so it can withstand the demands you'd expect of industrial environments. Polyamide also serves as an insulator to protect you from electric shocks. With a current rating of 12A, you can rest assured that this header will perform reliably in high-power systems. Its 5.08mm pitch means there's a safe distance between conductors to prevent short-circuits. You'll find this device useful in a wide range of applications, particularly in the electronics and automation sectors.

• Rated surge voltage of 4kV to withstand sudden power spikes
• UL94 V0 classification indicates it will stop burning within 10 seconds in the event of a fire
• Voltage rating of 320V makes it suitable for low-voltage operations
