DSL03 is designed to protect DSL line drivers against surges defined in worldwide telecommunication standards. This device protects line drivers of various systems such as ADSL and VDSL. The low capacitance makes it suitable from ADSL to VDSL2 data rates. DSL03 is able to survive severe conditions even when used with downgraded or oscillating gas tube. DSL03 is packaged in a SOT23-6L.
High surge capability
Keeps its peak power capability up to Tjmax
Voltages: 10, 22 and 24 V
Low capacitance device: Ctyp= 0.5 pF
Low leakage current: 0.2 μA at 25 °C
2.5 kV 2/10 μs - 500 A 2/10 μs
AC power fault tests
6 kV 10/700 μs - 150 A 5/310 μs
power induction tests
power contact tests
15 kV (air discharge)
8 kV (contact discharge
±1 kV, 42 Ω
8 kV
