A9DA2616, Schneider Electric RCBO, 16A Current Rating, 1P+N Poles, 30mA Trip Sensitivity, Type C, Acti9 Range, Автоматический выключатель

Schneider Electric RCBO, Type C, 6kA Breaking Capacity - Idd40 Series - A9DA2616

Use this residual current breaker with overcurrent protection (RCBO) from Schneider Electric to protect equipment and users from electrical hazards. It monitors the flow of electricity in your circuit and cuts power if it detects an overload, short circuit or earth leakage. Tough thermoplastic housing provides both impact resistance and effective insulation to safeguard you from electric shocks. For added safety, the unit's electrical terminals are designed to be touch-proof. With a trip sensitivity of 30mA, you can rest assured of an instantaneous response time to earth faults in domestic, commercial and industrial environments.

Features & Benefits

• Compact dimensions of 36 (W), 73 (D) and 85mm (H) for space efficiency in small enclosures
• Easy clip-on DIN rail mounting saves time and effort
• 4kV rated impulse withstand voltage to handle sudden power surges
• Mechanical service life of 20,000 cycles for long-term performance

Applications

• Industrial and commercial buildings
• Conveyors
• Power and control circuits

How much does this RCD weigh?

This device has a light weight of 210g so it's easy to handle and won't strain your equipment.

Datasheet A9DA2616

Product Environmental Profile
