470227, ABB SN201 MCB, 1P+N, 1A Curve C, 230V AC, 4.5 kA Breaking Capacity

ABB MCB, 1P+N Configuration, Toggle Actuator - SN201 Series - 470227

Safeguard your circuit from electrical faults with this MCB from ABB. Its 1P+N configuration means it offers protection for single-phase networks and will trip both the live and neutral connection in the event of overload. The unit has a 1A current rating, which means it's a practical choice for low current-consuming appliances. Its robust thermoplastic housing resists impact and scratches, so it can handle challenging environments. The material is also insulated to minimise the risk of electric shocks during installation and operation, enhancing safety. A front toggle switch makes this MCB easy to reset after it's been triggered.

• Can accommodate flexible, solid and stranded cables for versatility
• Coloured indicators for easy identification of contact position
• Electrical endurance of 20,000 operating cycles assures you reliable long-term performance
• Finger-safe terminals prevent accidental contact with live parts during operation for enhanced safety

Applications

• Power tools
• Cleaning equipment
• Industrial fans

The SN201 series miniature circuit breaker is a 1P+N single-module device for the protection of circuits against overload and short circuit. It is suitable for the application in final distribution and protection of long cable lenghts in TN and IT systems. This product is suitable for installations where neutral on the Left is needed.

How do I mount this MCB?

This MCB is designed for simple clip-on mounting onto a DIN rail. This process can be done without tools, saving time and effort.

Is this MCB waterproof?

This unit isn't protected against water, so you must keep it away from moisture to ensure optimal performance.
