SCOTCH 23 7X25, 3M Scotch 23 Black EPDM Electrical Tape, 25mm x 7m, Изоляционная лента

Scotch® Rubber Splicing Tape 23

Scotch® Rubber Splicing Tape 23 is a highly conformable 0.76 mm thick, self-amalgamating EPR (Ethylene Propylene Rubber) base for rubber splicing. It is designed to splice and terminate cables with overload temperatures of 266 degrees F(130 degree C), due to dissipating heat affectively. The snakeskin liner is easily removed when applying the tape, to allow the self-fusing ethylene propylene rubber, high insulating voltage tape.

Features and Benefits

• Features a special polyester liner that will not stick when unwinding
• Stretch up to 100% for void-free, moisture-resistant insulation
• Non-vulcanising and shelf stable
• Highly conformable, self-amalgamating EPR (Ethylene Propylene Rubber) based tape
• Ideal for moisture sealing electrical connections
• Black
• Self-fusing, ethylene propylene rubber backing and highly conformable, rubber-resin adhesive
• Temperature rated for continuous adhesion to 90°C
• Stretch up to 100% for void-free, moisture-resistant insulation
• Special polyester liner keeps tape protected and clean during application
• Non-vulcanising and shelf stable
• ASTM Approved & RoHS 2002/65/EC Compliant

Application

• Use Scotch® Rubber Splicing Tape 23 for low or high voltage applications and joints up to 69 kV.
• This 0.76 mm thick, highly conformable, self-amalgamating EPR (Ethylene Propylene Rubber) based tape can be stretched up to 100% for void-free, moisture-resistant insulation.
• It’s non-vulcanising and shelf-stable with excellent electrical properties.
Featuring a special polyester liner that will not stick when unwinding, this tape is ideal for moisture sealing electrical connections.

Can wires with exposed cables be made safe with this tape?

Yes, the electrical tape is designed for this purpose, but would recommended seek professional advice to deal with exposed wires.

3M Electrical Tape, 0.76mm Thickness, 1.4KN/m Tensile Strength - SCOTCH Series - SCOTCH 23 7X25

Improve safety with this electrical tape from 3M. Thanks to its effective heat dissipation, you can use it to splice and terminate cables with overload temperatures up to +130°C. High insulation properties let you wrap low-voltage wires that handle up to 69kV. The self-amalgamating EPR base is water-resistant for use in humid conditions, while high tensile strength supports tight wrappings to keep out moisture.

• Polyester lining provides protection and keeps the surface clean when applied
• Broad operating temperature range between -29°C and +130°C for use in harsh conditions
• ASTM approval assures you the tape has passed safety and quality testing
• RoHS compliance indicates no more than minimal amounts of any harmful materials

Applications

• Solid dielectric cables
• Jacketing on high-voltage splices
• Busbar insulation
• End-sealing of cables

Can I use this electrical tape outdoors?

Yes, it withstands splitting, cracking and flagging so it's suitable for outdoor use.

Why choose 3M?

3M are a trusted name in tapes and adhesives. Whether for industrial or even domestic applications, 3M has a tape to suit your needs. From automotive masking to office supplies, 3M tapes are relied on by millions to get the job done. RS supplies a wide range of quality 3M tapes to suit the needs of the most discerning customer.

3M Tape Selector

Need advice on choosing the right Tape? Use our Product Selector to help you make the right choice!

Splicing Tape Scotch 23

3M MRO Cable Jacket

Brochure - Rubber, Mastic and Specialty Tapes Application Guide
