RS PRO Signal Conditioner, Current, Voltage Input, Current, Voltage Output, 24 → 240V ac/dc Supply

RS PRO Isolating Signal Converter with Current, Voltage Inputs

If you need to change your electrical signal from current to voltage without interference, use this isolating signal converter from RS PRO. It features three-way isolation to prevent signals becoming crossed and keep conversion efficient.
You can mount this product to a DIN rail for a quick and secure attachment that's compatible with most standard fittings. The micro-compact design means you can install it even in tight assemblies where space is at a premium.
The converter's LED indicator lights up green so you can see when the device is working from a distance or in dark conditions. It also has an Ingress Protection (IP) rating of IP20, so it's touch-proof and safe from tampering or accidental damage from particles over 12 mm.

Features and Benefits

• Input ranges of 0 to 1 V, 0 to 2 V, 0 to 5 mA, 0 to 5 V, 0 to 10 mA, 0 to 10 V, 0 to 20 mA, 0 to 20 V, 0 to 60 mV, 0 to 100 mV, 0 to 300 mV, 0 to 500 mV, 2 to 10 V, 4 to 20 mA, ±5 mA, ±20 mA
• Current and voltage input types
• Isolating signal converter module type
• DIN rail mounting type
• Operating temperature range of -25°C to +60°C
• Output ranges of 0 to 10 V, 0 to 20 mA, 4 to 20 mA
• Current and voltage output types
• Analogue to analogue signal conditioner type
• Three-way Isolation
• Supply voltage of 24 to 240 V AC/DC
• Screw termination

Datasheet
