1729128, Phoenix Contact MKDSN 1.5/ 2-5.08 Series PCB Terminal Block, 2-Contact, 5.08mm Pitch, Through Hole Mount, 1-Row, Solder

Phoenix Contact MKDSN 5.08mm Pitch PCB Terminal blocks

The MKDSN range of PCB terminal blocks from Phoenix contact are great 7.62mm blocks that are through-hole and can easily be wave soldered to the PCB. These PCB Terminal blocks feature a low-temperature rise thanks to maximum contact force and have integrated protective guards that prevent you incorrectly inserting the conductors underneath the tension sleeve. The MKDSN terminal blocks are also a 5.08 mm pitch to have an increased voltage up to 400 V.

They're made from a durable and strong PA (Polyamide-Nylon) material and the material of the contact is CU (Copper). Furthermore, you simply just need to strip 8mm from your wire and insert them into the ports and simply tighten down an M3 screw for a secure and reliable connection over a long time.

Features and benefits:

• Allows connection of two conductors


• Protective guides prevent you from incorrectly inserting the conductors underneath the tension sleeve


• Worldwide known connection gives you maximum extensive compatibility


• Latching on the side of the unit enables various mounting positions to be combined


• Nominal current of 13.5 A


• Allows quick and easy connection to circuit boards once you've soldered it


• 5.08 mm Pitch

Phoenix Contact PCB Terminal Block, 17.5A Nominal Current Rating, 400V Nominal Voltage Rating - MKDSN 1,5/ 2-5,08 - 1729128

Want to keep the wiring on your circuit board in good order? Grab this PCB terminal block from Phoenix Contact. To simplify your layout, it creates a linking point for two circuits. As it measures only 8.1 (L) x 10.16 (W) x 13.5mm (H), it takes up just a small amount of space. Highly conductive copper alloy contacts transfer clear signals without a hitch. They're also tin-plated to resist rust in damp or humid settings.
The unit's screw terminals come with connection sleeves to deliver maximum contact force, which reduces resistance and minimises temperature rise in demanding applications. They also have protective guards that help prevent the incorrect insertion of conductors. A tough PA shell insulates and protects the connections to boost workplace safety.
Overall performance varies according to the derating curve, but you can confidently use this device in temperatures between -40°C and +100°C. Thanks to its 630V voltage rating, this terminal block works a treat in heavy-duty medical, industrial and aerospace systems.

Features & Benefits

• Through-hole mounting makes installation quick and easy
• Accommodates 26 to 16AWG wire sizes, making it a versatile option
• Self-extinguishing material limits the spread of fire

Approvals

UL (E60425); CSA (LR13631)

Approvals

UL (E60425); CSA (LR13631)

Datasheet 1729128

Line Drawing - 1729128
