TEN 40-2412E, TRACOPOWER TEN 40E DC-DC Converter, 12V dc/ 3.33A Output, 18 → 36 V dc Input, 40W, Through Hole, +85°C Max Temp, Преобразователь

Traco Power DC-DC Converter, 12V DC Output Voltage, Through-Hole Mounting - TEN 40E Series - TEN 40-2412E

This DC-DC converter from Traco Power kicks out a steady supply to keep your 12V DC device on the job. A wide input range between 18 and 36V DC means it handles voltage spikes and dips without issue, preventing damage to itself and any connected equipment. Thanks to its 92% efficiency, the unit keeps a lid on excessive heat build-up. Isolation between incoming and outgoing feeds beefs up safety, as there's no contact between these two elements of your circuit. You can save power and limit inrush currents in heavy-duty industrial operations with the handy remote on/off function.

Features & Benefits

• Through-hole mounting for speedy and secure installation
• Short-circuit protection safeguards equipment from electrical faults
• Wide operating temperature range between -40°C and +85°C for use in challenging conditions

Applications

• Medical equipment
• Consumer electronics
• Building automation systems
• Industrial assembly and packaging lines

How much space does this DC-DC converter need on a PCB?

With dimensions of 50.8 (L) x 25.4 (W) x 10.2mm (D), it's a small device that easily squeezes onto densely packed PCBs.

Datasheet TEN 40-2412E
