TEN 40-4812WIE, TRACOPOWER TEN 40WIE DC-DC Converter, 12V dc/ 3.33A Output, 18 → 75 V dc Input, 40W, Through Hole, +85°C Max, Преобразователь

Traco Power DC-DC Converter, 92% Efficiency, 40W Power Rating - TEN 40WIE Series - TEN 40-4812WIE

Turn your voltage down a notch with this DC-DC converter from Traco Power. Thanks to its 4:1 ratio, it has a wide input between 18 and 75V DC, so you'll have no trouble matching it to your supply voltage. The converter safely lowers this to 12V DC, using functional isolation to keep the input and output electrically separated. Load regulation ensures a ±1% accuracy, enabling the unit to feed sensitive circuits. With a maximum efficiency of 92%, it won't waste power or run too hot.

Features & Benefits

• Remote on and off controls help you save power
• Trim function gives you an output voltage adjustment of ±10%
• Through-hole mounting for a secure connection to PCBs
• Wide operating temperature range between -40°C and +85°C, to handle harsh conditions

Applications

• Industrial machines
• Process control
• Safety systems
• IT equipment
• Production lines

Is this DC-DC converter reliable?

Yes. Protections against short circuits and overvoltage and a metal case that provides shielding on all sides make this DC-DC converter a reliable workmate.

Datasheet TEN 40-4812WIE
