RS PRO Control Cable, 7 Cores, 1 mm², SY, Screened, 50m, Transparent PVC Sheath

RS PRO 7 Core SY Control Cable 1 mm², 50 m, Screened

This 7 core SY control cable from RS PRO is designed to regulate your electrical equipment in demanding environments. The cable design ensures maximum flexibility and allows you to adjust to fit ports that would otherwise be out of reach.
The copper conductor is protected by a galvanised steel wire braid (GSWB) which prevents the build-up of rust and corrosion over time. For any damage that does occur, the transparent PVC sheath will make it stand out so you can repair it quickly.
Use this cable in damp or arid internal environments. It can also withstand contact with oil-water mixtures.

Features and Benefits

• Armoured
• Polyvinyl chloride (PVC) insulation, bedding and sheath material
• Multicore cable shape
• Annealed copper conductor material
• 32 core strands of 0.2 mm
• Cross-sectional area of 1 mm²
• Earth cable
• Length of 50 m
• Maximum operating temperature of +70°C
• Minimum operating temperature of -15°C
• Minimum bend radius of 6 x diameter
• Seven cores
• Outer diameter of 12.2 mm
• Galvanised steel screen type
• Screened
• Transparent sheath colour
• Galvanised steel wire braid (GSWB) shielding
• Complies with BS EN 50525 standards
• Voltage rating of 300/500 V
