SXE9573-A81-00/110VAC, Norgren 5/2 Pneumatic Solenoid Valve - Solenoid/Spring SXE Series 110V ac, Клапан

IMI Norgren Pneumatic Solenoid Valve, 5/2 Configuration, 110V AC Solenoid Voltage - SXE Series - SXE9573-A81-00/110VAC

Precisely manage the airflow in your system with this solenoid valve from IMI Norgren. Its 5/2 configuration features individual exhausts for each device port, giving you close control over the airflow to and from your equipment in pressure-sensitive applications. The component's high 1,230l/min flow rate provides a reliable air supply to maintain your system's efficiency. Made from durable die-cast aluminium, the unit prevents disruption from impacts and corrosion to perform even in demanding industrial settings.

Features & Benefits

• Wide operating pressure range between 1.8 and 10 bar to handle intense loads
• Supports operation with lubricated media for added versatility
• NBR seals ensure minimal air loss through leakage
• Fitted with a 110V AC solenoid coil for wide compatibility with existing power supplies

Applications

• Automated assembly lines
• Bottling plants
• Positioning tasks
• Logistics industry

Can I use this solenoid valve outdoors?

Yes, you can. The valve has an IP65 rating which means it's fully protected against dust and low-pressure water jets. Thanks to this and its corrosion-resistant aluminium housing, you can rest assured the valve will perform in harsh outdoor conditions.

ISO 1 PRESS REG-PORT 4 Data Sheet

ISO*STAR (SXE, SXP) 5/2 & 5/3 Series Datasheet
