45789 RST 5-3-RKT 5-3-226/5 M, Lumberg Automation Straight Male 3 way M12 to Straight Female 5 way M12 Sensor Actuator Cable, 5m

Belden Lumberg Automation Sensor Actuator Cable, A-Coded, 60V Voltage Rating - RST Series - 45789 RST 5-3-RKT 5-3-226/5 M

Looking for a dependable connection between your switch and controller? You're in safe hands with this sensor actuator cable from Belden's Lumberg Automation range. It's double-ended, so there's no need to wire it directly and coupling screws keep it securely plugged in. The connectors are M12-sized with an A coding to work with standard automation devices. Thanks to PP insulation and a PUR jacket, the cable is rugged and offers good resistance to microbes and hydrolysis. Copper conductors and gold plating on the contacts boost reliability.

Features & Benefits

• Bend radius of at least 10 times its 4.6mm diameter for high flexibility
• Free from silicone, it's handy for coating applications
• Self-extinguishing PVC-free material boosts fire safety

Applications

• Industrial automation
• Automotive industry
• Plant machinery

What IP rating does this cable have?

This cable achieves an IP69K rating, meaning it's dust-tight and able to withstand high pressure and temperature washdowns.

Datasheet - 71725
