H8800VAAAB, Arcolectric Single Pole Single Throw (SPST), On-Off Rocker Switch Panel Mount, Клавишный переключатель

Min. Slimline Rocker Switches

From the 8800 series, a high-quality Ultra-Thin rocker switch designed for panel mounting. The non- illuminated slim line rocker switches are traditionally used for applications where valuable space is at a premium. Fitting is easy, once the recommended panel cut-out is made the single pole switches simply snap into the panel and are securely held in place. The 8800 series of slimline rocker switches are suitable for Class II equipment and support an IP40 splash resistant rating. The slender latching rockers are ideal for maintenance, repair, new designs, and prototype work.

Features and Benefits

• Ultra-thin profile
• I/O marking
• Curved actuator
• Suitable for Class II appliances
• AC Mains rated
• IP40 ingress protection
• Connection via 4.8 x 0.8 mm quick connect terminals
• Latching on-off actuation

Typical applications for Ultra-Thin rocker switches

Rocker switches are one of the most frequently used types of electrical switch. Due to the simple design and easy operation, rocker switches are found in a vast array of applications. Some of the most common are:

• Audio visual equipment
• Consumer electronics
• Test instruments
• Laboratory equipment
• Portable equipment
• Power supplies
• Computers and peripherals

FAQ

• Are the Ultra-Thin rocker switches easy to connect?
Yes, as the SPST rocker switches have male quick connect 4.8 x 0.8 mm tab terminals at the rear so the connection is easy. Simply select the appropriate red, yellow or blue female push on receptacle connectors according to wire size required.

Approvals

ENEC; UL; CSA

Approvals

ENEC; UL; CSA

NF 29259/260

UL RECOGNISED E45221

CSA LR10990-51

ENEC 137195-01

Datasheet
