SSA-115-S-T, Samtec SSA Series Straight Through Hole Mount PCB Socket, 15-Contact, 1-Row, 2.54mm Pitch, Through Hole Termination

Samtec PCB Socket, PET Polyester Insulation, +215°C Heat Deflection Temperature - SSA Series - SSA-115-S-T

Looking for hitch-free signal transmission for board-to-board connections? Choose this PCB socket from Samtec. It links directly to headers on the mating board, eliminating the need for wires and giving you a tidy network setup. Thanks to its highly conductive phosphor bronze contacts, you get smooth signal transfers. The component's PET polyester insulation keeps electrical hazards at bay, ensuring safe handling. Through-hole mounting provides a firm link to your circuit board, so the unit doesn't give in to vibration.

Features & Benefits

• Compatible with headers in the TS (200-1508), BBL (766-6427) and BHS series for versatility
• Tin plating improves resistance to corrosion for long-term performance
• 15 contacts let you make multiple connections
• Pitch of 2.54mm provides safe spacing between pins to prevent short circuits

Applications

• Consumer electronics
• Audio and music equipment
• Security and surveillance systems

What's the heat deflection temperature of this PCB socket?

The heat deflection temperature of this unit is +215°C. This means it withstands high temperatures without deforming, making it a safe bet for harsh environments.

Datasheet - SSA
