MR3A14BVBN, Key Instruments MR3000 Series Variable Area Flow Meter, 0.4 L/min → 5 L/min

1982919
Номер производителя: MR3A14BVBNПроизводитель: Key Instruments
Цена за шт.
22458.00 руб. (С НДС) *
Количество 5+
Цена 21762.00 руб.

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Key Instruments Flow Meter

The Key Instruments MR3000 series variable area flow meter measures the gas flow rate of 0.4L/min to 5L/min. This is a high tech, moulded, low cost manufactured from high impact polycarbonate. It can operate at pressures of 100psig and temperatures of 150°F (65°C). These economically designed units provide high-quality and accuracy when installing properly. The durability of the polycarbonate allows the flow meter to provide years of trouble-free service. It is supplied with scales in LPM and SCFH for air, or CCM and GPH for water.

Inclusions:
Mounting brackets and built-in bezel.

Features and Benefits

Pipe diameter range is 1/8 in
Connection type is 1/8 NPT female
Maximum operating pressure is 6.9bar
Maximum operating temperature is 65°C
high-quality construction
10:1 turn direct reading scales
Monitor or control air and water flow
Supplied with east to read 10:1 turn direct reading scales
Fittings made of brass
Seal material is VITON W/ stainless steel

Applications

It is use with air and water
Ideally suited for OEM applications

Техническая спецификация
pdfFlow Meters - Polycarbonate
pdfSeries MR Flow Meter
Диапазон диаметра трубы:
1/8 in
Максимальная температура среды:
+65°C
Максимальное давление:
6.9бар
Максимальный рейтинг расхода:
5 Л/мин
Материал:
Поликарбонат
Минимальная скорость потока:
0.4 Л/мин
Мониторинг информации:
Gas
Рабочая температура - максимальная:
+65°C
Серия:
MR3000
Соединение - тип:
1/8 NPT Female
Тип девайса:
Variable Area
