10-2J12.1069, EAO White LED Indicator Lamp, 24V ac/dc, T1 3/4 MG Base, 6.1mm Diameter, 750mcd

EAO Indicator Lamp, 2.5 to 5mA Operating Current, 750mcd Brightness - 10-2J12.1069

On the hunt for a long-lasting signalling solution for your circuit or panel? Look no further than this indicator lamp from EAO. Thanks to its bright white lamp with an illumination intensity of 750mcd, it's a doddle to spot in most light conditions. This means you can quickly flag faults and monitor the operating status of your equipment. As its base has a standardised T1 3/4MG size, you'll find it easy to connect to a compatible socket.

• Voltage rating of 24V AC/DC for compatibility with low-voltage systems
• Compact dimensions of 16 (L) x 6.1mm (diameter) mean it will take up minimal space on your panel

Applications

• Dashboard lights
• Telecommunications systems
• Machine status indication

The EAO single LED has and operating voltage of 24 V +10 % AC as well as DC and operating current 2.5 / 5 mA ±15 %. The colour of the LED is white and has a T1 MG socket.

Does this light have a warm-up period?

Lumi. intensity 750 mcd
Dom. wavelength x0.31/y0.32 nm

No. As it uses LED technology, the light reaches full brightness instantly when you turn it on.

What's the advantage of an LED lamp over incandescent alternatives?

LED lamps offer around fifty times the longevity of traditional incandescent bulbs and don't produce as much heat, so you can rest assured they're a safe and durable choice.

Datasheet - 10-2J12.1069
