TMR 6-0515, TRACOPOWER TMR 6 DC-DC Converter, 24V dc/ 250mA Output, 4.5 → 9 V dc Input, 6W, Through Hole, +78°C Max Temp

Traco Power DC-DC Converter, 84% Efficiency, SIP-8 Format - TMR 6 Series - TMR 6-0515

Balance the energy supply to your device using this DC-DC converter from Traco Power. It accepts voltage between 4.5 and 9V DC from an input source and steps them up to an output of 24V DC. With compact dimensions of just 21.8 (L) x 9.1 (W) x 11.2mm (D), this unit is ideal for fitting onto a crowded board. A mean time between failures of 2,135,000 hours shows you can rely on it for long-term use with minimal risk of downtime.

Features & Benefits

• Remote on/off control enables hassle-free configuration
• Continuous short-circuit protection to handle fault currents
• Voltage set accuracy of ±1% means reliable output every time
• Low ripple and noise of 50mVp-p, so there's minimal signal interference
• Non-conductive plastic housing is flame-retardant for safety in the event of a fire

Applications

• Computer peripherals
• Laboratories
• Storage facilities
• Measuring instruments
• Energy industry

What's the startup time of this converter?

This converter has a maximum startup time of 10ms to get your process up and running fast.

How efficient is the unit?

Thanks to its efficiency rating of 84%, you can rest assured that this converter doesn't waste energy by producing heat.
