M/163/15, Norgren Air Reservoir 150 ml, G 1/8, M/163 Series, 10bar

IMI Norgren Air Reservoir, -20°C to +80°C Operating Temperature, 63.5mm Bore - M/163 Series - M/163/15

Prevent your pneumatic systems from running out of puff with this air reservoir from IMI Norgren. It receives air through a flow valve and stores it for later use by your equipment. The unit also has a cooling effect on the compressed air and helps stop your machinery from overheating. When a compressor fails, this device provides a reserve of air that keeps critical processes running until the problem gets fixed. As it has a maximum time delay of 18 seconds, it activates pneumatic parts only when necessary, giving you precise control over machine operations.

Features & Benefits

• Bore size of 63.5mm for connection to standard equipment
• Regulation G1/8 thread for straightforward installation with commonly used components
• Storage volume of 150ml ensures a steady air supply in your system
• Operates at a broad pressure range between 0 and 10 bar for versatility

Applications

• Food and beverage production
• HVAC systems
• FMCG manufacturing industry

What temperature range does the air reservoir work in?

This component works at its best in an operating temperature range between -20°C and +80°C, so you can trust it to handle challenging environments.

Air Reservois M/163 & M/164
