2CSR275180R1064 DS201 M C6 A30, ABB RCBO, 6A Current Rating, 1P+N Poles, 30mA Trip Sensitivity, Type C, System Pro M Compact Range

ABB RCBO, Rail Mounting, 2.6W Total Power Loss - DS201 Series - 2CSR275180R1064 DS201 M C6 A30

Cut electrical supply issues off in a flash with this RCBO from ABB. By breaking for current leakage and overloads, it provides solid protection against common power faults. Thanks to its instantaneous function, the unit trips straight away to minimise the risk of hardware damage. Resets are done with a flick of the front-facing toggle lever, meaning your system is up and running again quickly and downtime is minimised. Mounting this breaker is speedy, thanks to tool-free installation on a DIN rail.

Features & Benefits

• Short-circuit breaking capacity of 10kA for effective surge protection
• Labelled poles clearly identify connections for simple wiring
• Electrical service life of 10,000 operations, providing long-term safeguarding
• Colour-coded status indicator, signalling contact positions at a glance
• Screw terminals to secure conductor connections against movement

Applications

• Packaging lines
• Engineering workshops
• Plastic processing

How do I know when this RCBO has tripped for a power fault?

A blue indicator appears on this unit's lever when it detects a fault, so it's easy to spot issues with your electrical supply as they occur.
