Festo Shock Absorber, YSRW-12-20, 72.5mm Body Length, M16 Thread Size

Festo Shock Absorber - YSRW Series - YSRW-12-20

This pneumatic shock absorber from Festo is suitable for use in a hydraulic cylinder. It cushions the impact of a moving piston and prevents damage and unnecessary wear to moving parts. The unit is self-adjusting and automatically reacts to the force applied to it. It has a built-in pressure spring to mechanically move the piston rod back to its original position. The component's seals are made from nitrile rubber (NBR), which offers resistance to heat and corrosion.

• Stroke length of 20 mm
• Maximum impact speed of 3 m/s
• Reset time range of 0.3 s to 1 s
• Pushing action mode of operation
• Cushioning length of 20 mm
• Maximum stop force of 1000 N
• Reset force of 5 N
• Housing material of galvanised steel
• Piston rod material of high alloy steel
• Operating temperature range of -10°C to +80°C
• Locknut mounting
• Weight of 78 g

Range Information

• The YSRW series of pneumatic shock absorbers is designed to improve production quality by moderating the damaging side effects of motion, noise and vibration
• The range features galvanised steel housings that are resistant to corrosion and stand up to the demands of high-temperature applications

The Festo push-in sleeve has push/pull principle of structure which used PBT type of housing material. Its nominal size is 3.8mm and can be assembled in any position.

Container size 50
Ambient temperature -10 to 80 °C
