Festo Pneumatic Compact Cylinder - 14056, 40mm Bore, 100mm Stroke, DZH-40-100-PPV-A Series, Double Acting

Festo Pneumatic Compact Cylinder, Aluminium, 0.6 to 10 Bar Operating Pressure - DZH-40-100-PPV-A

Looking for a reliable way to produce linear motion in your automated systems? Turn to this pneumatic compact cylinder from Festo. It has a double-acting function, which means it drives the piston rod back and forth by moving compressed air through two ports. Both ends of the unit feature adjustable cushioning to protect the rod from wear and damage caused by impact as it moves. An operating pressure range between 0.6 and 10 bar makes this a suitable option for use in low-pressure applications.

Features & Benefits

• Aluminium housing, TPE-U(PU) seal and high alloy steel piston rod offer resistance to corrosion, wear and impact, making this a long-lasting device
• Broad operating temperature range between -20°C and +80°C to withstand demanding conditions
• Can be lubricated to achieve smoother operation

Applications

• Water treatment plants
• Oil and gas industry
• Marine technology
• Packaging machinery

How do I set this pneumatic compact cylinder up?

This pneumatic cylinder has a G1/4 thread to let you directly connect it with an existing port in your machine. For flexibility, you can mount it in any position.
