Festo Pneumatic Compact Cylinder - 161308, 63mm Bore, 10mm Stroke, DZF-63-10-A-P-A Series, Double Acting

Festo Pneumatic Compact Cylinder, 63mm Bore, 10mm Stroke - DZF-63-10-A-P-A

This pneumatic cylinder from Festo converts energy from compressed air to linear motion. It has a narrow width that allows it to fit into tight spaces, making it suitable for compact applications. As this is a double-acting cylinder, it's capable of providing both forward and backward movement. This is made possible by alternating air pressure between the two ports at its ends, which pushes the piston back and forth. For safe and reliable use, this non-rotating cylinder features an oval piston that stops the unit from twisting during operation.

• Advance and return stroke forces of 1870N (Newtons) and 1682N for heavy-duty application
• Nitrile butadiene rubber (NBR) seals to prevent air leakage for reliable performance
• 10 bar operating pressure limit for high-performance operations
• Compatible with proximity sensors for automated functionality
• CRC2 (corrosion resistance category) for moderate resistance to oxidation

Applications

• High-pressure (HP) compressors
• Conveyor systems
• Automated sorting and handling

What can cause failure in this cylinder?

The most common causes of failure in this cylinder are contamination from dust and lack of lubrication. Schedule regular maintenance checks to stay on top of these.

Datasheet - DZF-63-10-A-P-A

Catalogue - Flat Cylinders
