BTI24-12S130D, Bellnix BTI DC-DC Converter, 12V dc/ 0 → 1.3A Output, 9 → 36 V dc Input, 15W, PCB Mount, +85°C Max Temp

The Bellnix BTI series is an isolated DC-DC converter that achieves industry-leading capacity density of 15 W in a small package of 1 x 1 inch. The power increase due to future function upgrades can be handled without changing the board with the same shape BTJ series (30W). It is a high efficiency (90%), and corresponds wide Input V range (9 to 36V, 18 to 76V). There are 12 models lined up.

High efficiency
Small size, 1x1 inch
Wide input voltage range 4:1
6 sided shield structure
Adjustable output voltage
Dual power supply usable as single power supply
Isolation voltage DC1500V (1min)
Over current protection
No electrolytic capacitor, No tantalum capacitor
DIP package
Heat sink not required
Operating temp Ta = -40°C to 85°C
RoHS compliance

Datasheet - BTI24-12S130D
