HEL-1/8-D-MINI, Festo 2/2 Closed, Monostable Pneumatic Manual Control Valve HEL Series, G 1/8, 1/8, 165076

Festo Monostable Pneumatic Manual Control Valve, 2/2 Closed - D Series - HEL-1/8-D-MINI

This pneumatic on/off valve from Festo protects your air and gas flow systems from damage. It does this by making sure pressure builds up gradually during start-ups. Manufactured from corrosion-resistant die-cast aluminium, it functions reliably even in demanding industrial environments. The valve aids accurate and leak-free alignment in air-preparation units thanks to its soft seal. The product's robust design ensures it will last long in applications with standard compressed-air requirements. This component is part of Festo's D Series range of modular air-preparation components. You can use it in your bespoke pneumatic system.

• G 1/8 connection port thread
• Throttleable exhaust-air function
• Monostable valve function
• Suitable for any assembly position

Range Information

• D Series is Festo's strong and reliable air-preparation components range
• D Series valves are available in mini, midi and maxi sizes
• Items in the range are simple, streamlined and easy to assemble into modular units
• The range is corrosion-resistant against condensation in indoor applications (class CRC 2 to Festo standard FN 940070)
• Each unit complies with the EU Low-Voltage Directive for additional safety

The Festo HEL series pneumatic on-off valve is equivalent to monostable, 2/2 closed valve function. This is used in conjunction with service units for gradual pressure build-up.

Exhaust-air function = throttle able
Type of actuation = pneumatic
Sealing principle = soft
Assembly position = any

Datasheet - HEL-1/8-D-MINI

On-Off/Soft-Start Valves HE/HEE/HEP/HEL, D Series
