Festo 3/2 Closed, Monostable Pneumatic Manual Control Valve HEE-1/4-D-MINI-230 Series, G 1/4, G 1/8, 1/4in, 165073

Festo Pneumatic Manual Control Valve, G1/4 Thread, 3/2 Function - HEE-1/4-D-MINI-230

Manage the movement of air in your pneumatic system using this manual control valve from Festo. As it's a 3/2 valve, it can move in two directions to direct the air through three different ports. You can use this component with both compressed air and inert gases making it a versatile choice. A nominal flow rate of 1,500l/min means it can withstand high-flow applications. For durability, the device's aluminium die-cast housing is resistant to impacts and corrosion. You can mount this valve in any position for flexibility in your setup.

• Light weight of 223g for minimal strain on equipment
• Broad operating temperature range between -10°C and +60°C to withstand harsh environments
• NBR seals are resistant to oils and chemicals for added robustness
• Mechanical spring reset for rapid operation

Applications

• Marine engineering
• Packaging industry
• Industrial cylinders

How much pressure can this valve withstand?

This valve has an operating pressure range between 2.5 and 16 bar, which means it can withstand both low-pressure and high-pressure systems.

What type of power source does this valve use?

This valve is powered electronically. You can connect it to a power source through its built-in plug or via a DIN rail.

Datasheet - HEE-1/4-D-MINI-230
