Festo Solenoid Valve MN1H-2-1-MS, 2 port(s) , NC, 230/110/24 V, 1in

Festo Solenoid Valve, Brass, 10 Bar Maximum Working Pressure - MN1H-2-1-MS

Boost the performance of your system with this solenoid valve from Festo. It's a versatile option that controls and stops the flow of compressed air with a degree of filtration of 200μm. An electromagnetic coil opens and closes the valve, so there's no need for time-consuming manual intervention. As it can support high-temperature mediums between -10°C to +60°C, it's safe for use in industrial environments. A corrosion-resistant brass body and high alloy steel screws mean the device offers a long service life.

Features & Benefits

• Line mounting type for straightforward installation
• Manual override feature for enhanced workplace safety
• Closing time of 180ms and opening time of 120ms for reliably fast reaction
• Wide working pressure range of 0.5 to 10 bar for versatility

Applications

• Domestic appliances
• Power motors
• Larger industrial valves

What's the default valve position?

This valve has an NC default position for reliable continuous operation. For safety, this feature also ensures that the valve is closed if there's pressure loss in the control circuit.

What's the IP rating of this solenoid valve?

This unit carries an IP65 rating, indicating it's protected from dust and low-pressure water jets from any direction, so can be used in contaminated conditions.

Datasheet - MN1H-2-1-MS

Catalogue - Solenoid Valves MN1H-MS
