SKF 6324 M/C3VL0241 Single Row Deep Groove Ball Bearing- Open Type 120mm I.D, 260mm O.D

SKF Ball Bearing, 120 mm ID, 260 mm OD - 6324 M/C3VL0241

To reduce maintenance and machine downtime in the energy and utilities sector, choose this INSOCOAT ball bearing from SKF. It's designed with a coating to prevent electric current from passing through the bearing, so you don't have to worry about damage and wear on bearing surfaces. The bearings also protect the grease layer, which helps reduce friction and heat. This unit comes with a strong, lightweight machined-brass cage that's ideal for applications with low lubricant conditions.

• Open-end type bearing for low friction generation
• INSOCOAT type prevents damage due to electrical erosion
• Inside diameter of 120 mm, outside diameter of 260 mm for versatile application
• Compact race width of 55 mm

Application Information

• Electric motors and generators
• Wind energy sector
• Construction equipment

How is this bearing protected from electrical erosion?

The bearing is coated with a layer of aluminium oxide that essentially insulates it. This means electricity can't pass through the bearing, ensuring long and reliable service.

What's the internal clearance on this bearing?

This bearing has C3 internal clearance, which is considered larger than normal and is ideal for applications with very low torque and high loads.
