SS-102-TT-2, Samtec SS Series Straight Through Hole Mount PCB Socket, 2-Contact, 1-Row, 2.54mm Pitch, Solder Termination

Samtec PCB Socket, 2.54mm Pitch, 1A Current Rating - SS Series - SS-102-TT-2

Connect circuits efficiently with this PCB socket from Samtec. The connector mates with a compatible pin header (766-6483), making board-to-board links a piece of cake. As it's made of glass fibre-reinforced polyester, the unit withstands impact, wear and heat without a hitch. It's tough enough to handle challenging conditions, as it has a wide operating temperature range between -55°C and +125°C. Thanks to its compact pitch of 2.54mm, it's widely compatible with standard PCB headers and cards for ease of assembly.

Features & Benefits

• Precision-machined socket strip helps to ensure effective board spacing
• Straight body orientation for ease of wire termination

Applications

• Commercial and domestic appliances
• Consumer electronics
• Industrial control applications
• Aerospace systems

What type of contacts does this PCB socket have?

The component features highly conductive and corrosion-resistant beryllium copper contacts, so you can count on glitch-free signal transmissions.

How do I install this socket on my circuit board?

Mounting this socket is a breeze. Just punch the pins through the corresponding holes on your PCB and solder the connector in place.

Datasheet - SS-102-TT-2

Line Drawing - SS-102-TT-2
