TSW-115-14-T-S, Samtec TSW Series Straight Pin Header, 15 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded

Samtec TSW Straight Pin Header, 15 Contact, 2.54mm Pitch - TSW-115-14-T-S

This is a range of through-hole header strips designed for classic 0.100" pitch applications. The TSW series elevates the humble header strip with industry-leading design flexibility. With numerous lead styles, plating options, and pin configurations, this connector provides exceptional versatility for your design needs. Whether you require board-to-board, cable-to-board, or cable-to-cable solutions, the TSW-115-14-T-S delivers reliable performance and durability

Features & Benefits

• standardised pitch for compatibility with existing designs
• Reliable electrical connections and robust performance
• Space-saving design for efficient PCB layouts

Applications

• Suitable for various board-to-board connections
• Used in consumer electronics, industrial equipment, and telecommunications devices
• Reliable interconnects for automotive electronics
• Ideal for connecting modules and components

Is the TSW-115-14-T-S compatible with other Samtec connectors?

Yes, it is part of Samtec’s extensive connector ecosystem, ensuring compatibility with other Samtec products.

Can I use this header strip for high-frequency applications?

Yes, the TSW series offers various plating options, including those suitable for high-frequency signals.

What is the maximum current rating for this connector?

The TSW-115-14-T-S can handle currents typical for standard PCB applications.
