SKF Bearing End Cover, ECY 208

SKF Bearing Assembly, End Cover, 83mm OD, 28.5mm Width - ECY 208

Complete your bearing assembly with this end cover from SKF. It's a simple way to protect exposed shaft ends and boost safety. It's made from hardwearing polypropylene that resists chemical damage, so you can confidently use it in systems where oils and solvents are present. This flexible component is suitable for use with 62 and 63 Series deep-groove ball bearings. An extended inner ring with a locking device helps make mounting quick and easy.

• Withstands operating temperatures up to +100°C for use in challenging conditions
• Simple installation by snapping the cover into the groove on the housing
• Light weight of only 20g minimises strain

Applications

• Automotive industry
• Aerospace systems
• Military applications

Apart from safety, what other functions do bearing end covers perform?

Bearing end covers help with the axial positioning of the bearing to prevent misalignment. They also keep out corrosives such as dust to prolong the service life of components.

How do I choose the right bearing end cover?

You need to match the dimensions of the end cover to those of the bearing. The inner and outer dimensions must correspond to achieve a secure fit.

Datasheet - ECY 208

Catalogue - Y-bearings and Y-bearing units
