RS PRO Metallic Nickel Plated Brass Cable Gland, PG21 Thread, 9mm Min, 16mm Max, IP68

RS PRO IP68 PG Type ECM Cable Glands

From the trusted RS Pro brand, a range of IP68 EMC nickel-plated brass cable glands designed specifically to be used with copper-screened cables. The hexagon-shaped glands offer excellent cable retention and optimal strain relief ensuring a secure termination is maintained. The RS Pro PG type cable glands are constructed from nickel-plated brass with a flexible ECM contact which is easy to assemble, achieves a low resistance screen contact, strain relief and high protection class. With a choice of PG9 up to PG29 threads and various cable diameters, the RS PRO range of hexagon glands offers electrical engineers a reliable solution for numerous applications.

Features and Benefits

• IP68 ingress protection, providing protection from water, pressure and dust particles


• UL 94 V2 standards


• Made from nickel-plated brass


• Operating temperature range – 40°C to + 100°C


• For use with Non-armoured cable


• Supplied with locknut


• Flexible ECM contact for easy assembly


• PG9 to PG29 metric threads available (please see datasheet for more details)


• Various cable clamping sizes to suit your needs (please see datasheet for more details)

Applications

Cable glands are used throughout many industries to terminate and seal cable entries into electrical equipment and enclosures. They are vital accessories in ensuring cables are fitted and retained correctly providing a secure connection. Some of the most common areas to find cable glands are:
Robotics
Moving machine parts
Electrical Installations
Lighting
Wind and Solar
New Energy Vehicles

Environment

These RS PRO hexagon compression glands have an IP68 ingress protection rating. They are designed for use in areas that require dust and waterproof protection for extended periods of time.

Supplied with

Lock nut
