ESX10-105-DC24V-16A-E, ETA ESX10 Electronic Circuit breaker 16A 24V ESX10, 1 channels , Plug-In Mounting

The ETA ESX10 series electronic circuit protector r is only 12.5 mm wide and selectively protects all DC 24 V load circuits, thereby increasing the uptime of machines and systems. This is achieved by a combination of active current limitation in the event of a short circuit and overload disconnection typically from 1.1 times rated current. It responds faster than frequently used DC 24 V switch mode power supplies without tripping fast and thus prevents disastrous voltage dips of the supply.

Standard without physical isolation in the event of a failure
Without signal input
Signal output F signal output F (group signal, N/O)
Current rating: 16A
Active linear current limitation
Increases machine uptime through clear failure detection and stable power supply
Reduces downtimes through quick fault resolution
Simplifies planning through clear sizes and ratings
Saves costs and time through fast and flexible plug-in mounting

Datasheet - ESX10-105-DC24V-16A-E
