1SAE231111R0640, ABB ESB Series Contactor, 230 → 240 V Coil, 4-Pole, 25 A, 17.3 kW, 4NO

ABB Contactor, 500V Rated Insulation Voltage, 16 to 10AWG - ESB Series - 1SAE231111R0640

Shield your circuitry from arcs and spikes during start-up with this contactor from ABB. Potentially damaging surges are kept under control, thanks to the device's inbuilt 6kV rated impulse withstand voltage. There are four poles, so you can connect four circuits to one compact unit. It measures up at just 85 (H) x 36 (W) x 65mm (D), so it won't crowd out your enclosure. You can depend on reliable long-term performance in busy applications, as it typically delivers up to a million mechanical operations.

Features & Benefits

• 17.3kW power rating ensures it reliably handles high-power equipment
• Coil voltage rating between 230 and 240V for easy input compatibility
• 25A contact current rating for use with low-power systems

Applications

• Lighting control
• Heating systems
• Production lines

What's the normal state configuration of this contactor?

This contactor has a 4NO configuration, indicating its contacts are normally open and power won't flow until its coil is energised.

Does this unit function in harsh environments?

Yes. You can depend on it in temperatures between -25°C and +55°C, so it's an ideal choice for industrial workplaces.
