1SAE361111R0620, ABB ESB Series Contactor, 230 V ac Coil, 2-Pole, 100 A, 2.3 kW, 2NO

The ABB ESB100 installation contactors are used to control single and three-phase loads up to 100 A and can be operated by AC or DC. These contactors are made for use in household applications as well as in industrial environments. The following benefits are provided: Hum-free operation, low power consumption and integrated overvoltage protection.

Rated Operational Voltage:Main Circuit 220 V DC
Main Circuit 400 V AC
Rated Control Circuit Voltage (Uc):230 V
Rated Frequency (f):Control Circuit 400 Hz
Control Circuit 50 Hz
Control Circuit 60 Hz
Control Circuit DC
Main Circuit 50 Hz
Main Circuit 60 Hz
Main Circuit DC
Rated Operational Current AC-1 (Ie):(NO) 100 A

Datasheet-1SAE361111R0620
