SKF 4 Hole Flange Bearing Unit, FY 2. TF, 50.8mm ID

SKF Flanged Bearing Unit, 4 Mounting Holes, 50.8mm ID - FY 2. TF

Do you need a component to hold a shaft at a perpendicular angle? Choose this flanged bearing unit from SKF. It handles fast limiting speeds of up to 3600rpm for use in demanding applications. As it carries dynamic loads up to 43.6kN and static loads up to 29kN, this is a suitable option for heavy-duty use. Maintenance is easy thanks to the relubrication hole and nipple, which make it quick and simple to add more grease when necessary.

Features & Benefits

• Cast iron housing dampens vibrations to maintain a firm connection to the mounting surface
• Corrosion-resistant steel insert prevents rust build-up
• Operates in temperatures up to +100°C to handle friction heat common in high-speed motors
• Four equally spaced bolt holes for secure installation

Applications

• Industrial conveyors
• Manufacturing facilities
• Food processing industry

What accessories work with this flanged bearing unit?

To complete the bearing, add a PP end cover (209-3658). This protects the exposed shaft and reduces the risk of workplace accidents.

How do I mount this component?

It's easy to securely mount the device to a support surface with four 3/8-24 UNF set screws. Use a 4.763mm hexagonal key set and 16.5Nm tightening torque.

Datasheet - FY 2. TF

Catalogue - Y Bearings & Y Bearing Units
