C00201000, Norgren Pneufit C Series Union Tee, Push In 10 mm to Push In 10 mm, Threaded Connection Style, Pneufit

IMI Norgren Pneumatic Fitting, -0.9 to 10 Bar Operating Pressure, PBT Construction - PNEUFIT C Series - C00201000

Working with compressed air lines? Join them in seconds with this pneumatic fitting from IMI Norgren. On each end, it has a 10mm connector with an internal grab ring and collet – just push your tubing in to achieve a secure connection. It's a quick and simple job, with no tools required. As this mechanism holds tubes firmly without causing damage, it's a safe bet for use with softer PA or PUR types of 85 or 95 durometer thickness. A stem seal and U-packing inside the fitting help prevent your medium from leaking. This gives you system stability across an operating pressure range of -0.9 to 10 bar.

Features & Benefits

• Silicone-free, for a healthy working environment
• Also suitable for vacuum applications up to 750mm of Hg
• Suits an ambient and media temperature between 0°C and +60°C for reliable use in harsh environments

Applications

• Agricultural equipment
• Construction industry
• Chemical processing
• Textile manufacture

How durable is this fitting?

This fitting has a robust body constructed from impact-resistant PBT which, combined with the nickel-plated brass used for the metal elements, assures you of its long lifetime. It's also resistant to corrosion and contamination for additional peace of mind.

Datasheet - C00201000

Catalogue - World Class Motion & Fluid Control Solutions
